Rohde & Schwarz DVRM MPEG2 Realtime Monitor

Characteristics

R&S DVRM is the solution for the continuous monitoring of MPEG2 transport streams in real time. The measurements performed are necessary to ensure smooth interplay of all components of a DTV transmission network. Error signaling is via:

  • front-panel LEDs,
  • 12 relay contacts,
  • a remote-control interface.

R&S DVRM is controlled via the remote interface. It is designed for continuous operation, so all settings are stored in a non-volatile memory ensuring that the unit is immediately ready for operation again after a power failure. New remote settings are required only to modify operating parameters or read error statistics.

R&S DVRM comes with a PC software ("MPEG2 Realtime Monitor") for remote control of the unit. The software runs under Windows 95/98 or Windows NT. It communicates with R&S DVRM via a serial interface (RS232) and offers a COM/DCOM software interface.

Local control and display elements are not provided because R&S DVRM is intended for use in networked monitoring systems with one or several R&S DVRMs being integrated.
