Engineers involved in design, characterisation and validation of USB2.0 devices face daily pressures to speed new products to the marketplace. USB2.0 designers need tools to properly characterize their designs and verify compliance to industry standards. Characterisation of these electrical signals includes mask testing as well as parametric testing, up to 480 Mbps.

TDSUSB2 eliminates the tedium of manually setting up the oscilloscope by providing predefined oscilloscope setups for various tests. Users can quickly perform all USB-IF recommended tests, such as eye diagram and parametric testing for Low-speed, Full-speed and High-speed devices and hubs. The comprehensive test fixture supports a wide range of tests.

A comprehensive compliance test fixture provides a probing solution for the Signal Quality test, Inrush Current check, Drop and Droop test, Receiver Sensitivity and Impedance Measurement test. Connectors are available for the DG2040 data generator and TDS8000B sampling oscilloscope with TDR module. The test fixture is a standard accessory with TDSUSB2.
